• These switches substantially broaden the range of possible sounds on electric guitars.
  • They allow coil combinations on the pickups which are impossible to create using conventional standard switches.
  • Installation is simple – neither woodwork nor drill holes are required on the backplate.
  • Simply remove the wires from the old switch by heating the connections with a soldering iron, then remove the switch and replace it with the Megaswitch.
  • Solder the wires according to the diagram.
  • Possible Applications:
  • Type: S+T
  • Position: 3
  • Connections: 8
